ASME Section I · Saudi Arabia · 2025 · Power Boiler
Water Wall 20 Rows
20-row water wall panels in SA-213 T12, manufactured to ASME Code Section I (2021) and exported to Saudi Arabia.
Project Gallery
Project Photos
Click any image to view in full size · 8 images in gallery
Project Snapshot
Project Information
| Parameter | Details |
|---|---|
| Product | Water Wall Panel (20 rows) |
| Design Code | ASME Section I · 2021 |
| Country | Saudi Arabia |
| Year | 2025 |
| Material | SA-213 T12 |
| Max. Allowable Working Pressure | 19.7 MPa (197 bar) |
| Design Temperature | 440 °C |
| Corrosion Allowance | 0 |
| PWHT | Not Required |
| NDE Requirements | See Notes |
| Hydrostatic Test Pressure | 30.0 MPa (300 bar) |
| Hydrostatic Test Metal Temp. | 20 ~ 50 °C (70 ~ 120 °F) |
